KTA 970/KMH 980 Pilot’s Guide
Rev 2 006-18273-0000
1
TCAS I System Components
SYSTEM COMPONENTS
TRAFFIC DISPLAYS:
KMD 850
Compatible Radar Indicators via GC 362A
Compatible EFIS
TA/VSI
TCAS CONTROLS:
KMD 850
CP 66B TCAS I Controller
Discretes
OPTIONAL EGPWS CONTROLS & DISPLAYS:
KMD 850
Compatible Radar Indicators
Discretes
TOP ANTENNA
Discrete Control
TRAFFIC DISPLAY/CONTROL
OR
AUDIO PANEL
• Barometric Altitude - Gilham, ARINC 429
• Heading - XYZ Synchro
• Suppression
• Discretes
• Outside Air Temperature
KTA 970/
KMH 980
TCAS
PROCESSOR
Directional
KA 815
Directional
KA 815
Omni-Directional
(L-Band)
AIRCRAFT SYSTEMS
SYSTEM STATUS
• TAS VALID
• EGPWS INOP
CONFIGURATION MODULE
KCM 805
Headphone/600 Ohm
BOTTOM ANTENNA
GPS ANTENNA
KA 92
KMD 540
Comprised of the following cards:
KAC 502 (EGPWS) and/or
KAC 504 (Traffic)
Option 1
No Control Unit
Option 2
PWR
SBY
TST
A/B
FL
OR
KTA 970/KMH 980 Block Diagram
