B ATCRBS TRANSPONDER KT 76C
Rev 3, May 2004 IM 006-10545-0003.dwd Page 1-6
1.3.2 KA 60 PHYSICAL CHARACTERISTICS
1.4 UNITS AND ACCESSORIES SUPPLIED
1.4.1 CONFIGURATIONS AVAILABLE
Table 1-3 lists the available configurations of the transponder and the features contained in each
configuration.
Table 1-2 KA 60 Technical Characteristics
TSO Compliance: TSO C66a (DME)
TSO C74c (Transponder)
DO-160 Environmental Categories:
D2A/JY/XXXXXXXXXXX
Physical Dimensions: Height: 3.13 ± 0.2 inches (79.502 ± 5.08 mm)
Width: 0.95 ± 0.2 inches (24.13 ± 5.08 mm)
Length: 4.05 ± 0.2 inches (102.87 ±5.08 mm)
Weight: 0.20 lbs (0.09 kg)
Temperature: -55 °C to +71 °C
Altitude: 55,000 feet
Vibration: 0.2 inch/ 2g - 0.02 inch /5g
Shock: Rigid mounting 6 G operational 15 G crash safety.
Table 1-3 KT 76C Configurations Available
HONEYWELL
PART NUMBER
SUPPLY
VOLTAGE
LAMP
VOLTAGE
MOUNTING
RACK
CIRCULATOR
BOARD
066-01156-0101 11 - 33 Vdc 14 or 28 Vdc 047-09628-0004 200-09478-0010
066-01156-0201 11 - 33 Vdc 14 or 28 Vdc 047-09628-0004 200-09478-0020
