1.5 ACCESSORIES REQUIRED, BUT NOT SUPPLIED
The following parts are recommended for a cable setup with dimensions of 4.5 feet to 11 feet: (See
Figure 2-5, Sheet 1 of 2).
The following parts are recommended for a cable setup with dimensions of 10 feet to 25 feet: (See
Figure 2-5, Sheet 2 of 2).
The following parts are recommended for a cable setup with dimensions of 16 feet to 32 feet:
(SeeFigure 2-5, Sheet 2 of 2).
Table 1-5 Cable Setup 4.5 to 11 Feet
HONEYWELL PART NUMBER DESCRIPTION QUANTITY
006-01058-0005 Connector Assy Procedure 1
024-00051-0060 Cable, Coax 11 ft.
030-00092-0000 Connector, Coax Mod Type BNC 1
030-00101-0002 Connector, Coax 1
Table 1-6 Cable Setup 10 to 25 Feet
HONEYWELL PART NUMBER DESCRIPTION QUANTITY
006-01058-0005 Connector Assy Procedure 1
024-00072-0000 Cable, Coax 25 ft.
030-00102-0001 Connector, Type Unit 1
030-00435-0000 Connector, Antenna 1
Table 1-7 Cable Setup 16 to 32 Feet
HONEYWELL PART NUMBER DESCRIPTION QUANTITY
006-01058-0005 Connector Assy Procedure 1
024-00051-0060 Cable, Coax 6 in.
024-00071-0000 Cable, Coax 32.5 ft.
030-00101-0002 Connector Type Unit 1
030-00138-0000 Cable, Unit extension to antenna
connector
1
030-00434-0000 Connector, Antenna 2
