ACCESSORIES
order no. description
T7460LONJACK
Module for access to external buses
(5-pc. set)
T7460-LONJACK
The T7460-LONJACK (ordered separately) is a small board
with a 3.5 mm jack. When mounted to the Printed Circuit
Board (see Fig. 14), it provides easy access to external
buses.
Order quantity: set of 5 pieces
1234
5
67
CONNECTION
TERMINALS
PC
CONNECTION
DEBUG
CAL0
2000
3000
CAL400
Fig. 14. Mounting the T7460-LONJACK
