Honeywell CS071AE User Manual

CLEANING & MAINTENANCE
Cleaning The Honeycomb Cooling Media & Carbon Filter
Draining and Cleaning The Water Tank
•
•
•
14
Rear Grill Removal Screw
Back Grill
•
•
•
•
•
•
Turn the power “off” and disconnect the air cooler from the power supply.
Move the unit to a location where it can be drained.
Remove the cap from the water drain plug and allow the tank to empty (see parts description on
page 7).
Refill the water tank up to the maximum level with clean water and drain it completely.
Fill water tank and rinse at least 2-3 times before use.
Plug into the power supply and turn on unit.
Turn off the unit, and unplug the power cord from wall
outlet.
Rotate the unit facing the back panel, locate the Rear
Grill Removal Screw (refer page 7, #12) and remove with
the help of a screw driver.
Pull the back grill panel upwards, until it is completely
removed.
•
•
•
The air cooler is now ready to be used. This cleaning process should be repeated monthly to
maintain the integrity of the unit and to remove particles filtered from the air.
Plug into the power supply and turn on unit.
The Honeycomb cooling media & carbon filter can now be
seen. Clean the carbon filter & honeycomb with clean cloth
to remove all the dust & dirt particles.
Once cleaning is finished, reassemble the unit as
described above.

Honeywell CS071AE Specifications

General

Type	Monobloc mobile air conditioner
Timer type	Digital
Filter type	Carbon
Noise level	- dB
Variable power	Yes
Number of speeds	3
Water tank capacity	7 L
Cooling capacity (max)	- BTU/h
Timer duration (maximum)	7.5 h
Air conditioner functions	Cooling
Cooling capacity in watts (max)	50 W
Cooling capacity in watts (nominal)	- W
Cooling energy efficiency (EER, W/W)	-
Hourly energy consumption (cooling)	- kWh
Product color	White
Suitable for room area up to	9 m²

Weight and Dimensions

Depth	396 mm
Width	244 mm
Height	665 mm
Weight	5900 g
Package depth	430 mm
Package width	270 mm
Package height	705 mm
Package weight	7000 g
