Honeywell CT3500 User Manual

23 69-1199—4
Notice:
This thermostat is a Class B digital apparatus that complies with Canadian Radio Interference Regulations,
CRC c. 1374.
M10619
THERMOSTAT
1 POWER SUPPLY. PROVIDE
DISCONNECT MEANS AND OVERLOAD
PROTECTION AS REQUIRED.
1
1
5 - WI R E H E A T/ C OOL
( J U M PE R R E M OVE D )
HEATING
RELAY OR
VALVE COIL
COOLING
CONTACTOR
COIL
FAN
RELAY
B
R
RC OW Y
G
M18738
HEAT
RELAY
COMPRESSOR
CONTACTOR
COOL
DAMPER
1
POWER SUPPLY. PROVIDE
DISCONNECT MEANS AND
OVERLOAD PROTECTION
AS REQUIRED.
1
5 - WI R E H E A T/ C OOL WIT H DA M PE R
( J U M PE R I N T AC T )
B
R
RC OW Y
G
FAN
RELAY
HEAT
DAMPER
THERMOSTAT
