FC1: General Information 4
For other applications, i.e. with more than one stream and/or more than one
flow direction, more AFBs of the Flow Conversion and Gas Quality type are
used.
General rules:
• One
Flow Conversion AFB is necessary for each stream and for
each flow direction.
• One
Gas Quality AFB is necessary for each C calculation working
with different measurement data (pressure/temperature and/or gas
quality) or based on different calculation rules (as to calculation
standards and/or base conditions).
The
Flow Conversion and Gas Quality AFBs working with the same
measurement data are linked via parameterization. The parameterization
supports the grouping of AFBs in user-defined structures. This way, it is easy
to identify which AFBs belong together in both, the parameterization user
interface and the device screen.
Examples of typical applications:
1 stream, 2 flow directions, 1 gas quality measurement
For a flow computer application with one stream and two flow directions (fd 1
and fd 2), there have to be two sets of counters (one for each flow direction)
whereas the pressure, temperature and gas quality measurement has to be
performed only once. This means that two
Flow Conversion AFBs and
one Gas Quality AFB are necessary, provided that the same GQ
calculation standards and the same base conditions are to be applied to
both flow directions.
