5 FC1: Operation for Legally Relevant Functionalities
Qc
10
Flow rates QE Energy flow rate
QM Mass flow rate
Qb Base volume flow rate
Qc Corrected volume flow
rate
Qm Flow rate for volume at
measurement conditions
Table 11: Hyperlinks in Flow Conversion's main display
5.4.2 Gas Quality AFB
For most applications, the calculation of the conversion factor is performed
by the
Gas Quality AFB. The measurements used for this calculation are
indicated in the main display of the responsible Gas Quality AFB. As
shown in Table 10, this display can be activated by using the C conversion
factor hyperlink in the Flow Conversion AFB (fiscal display).
Alternatively, the main display of the Gas Quality AFB can be invoked by
using the corresponding button in the home display as usual.
The labels of some of the measurements that are shown in the Gas Quality's
main display are designed as hyperlinks, too.
Figure 10 shows a typical example of a Gas Quality main display; Table 12
lists the target displays of the hyperlinks as well as the values and
measurements included.
10
Qc is replaced by Qm if no gas meter correction is parameterized.
