Honeywell Enraf VITO User Manual

Average temperature measurement with MRT
___________________________________________________________________________
Instruction manual VITO Page 25
3.4 Troubleshooting
3.4.1 Temperature error request HCU/HPI (item EM)
This item helps you configuring correctly by showing the most recent temperature error encountered by the option
board.
xx00 No error xx70 Sub-system error. Check or replace VITO Interface board
xx50 Element 1 detected absent xx72 Not supported element type. Check item MT
xx51 Element 2 detected absent xx73 Wrong element configuration. Check item MN
xx52 Element 3 detected absent xx80 R_test error (out of limits)
xx53 Element 4 detected absent xx81 R_cable error (out of limits) or isolation resistance to ground too low
xx54 Element 5 detected absent xx84 Standard deviation too high or isolation resistance to ground too low
xx55 Element 6 detected absent xx91 Wrong J0 .. JD setting. Check these items.
xx56 Element 7 detected absent xx92 No data available. Check wiring or connection with VITO Interface
xx57 Element 8 detected absent
xx58 Element 9 detected absent
xx59 Element 10 detected absent
xx60 Element 11 detected absent
xx61 Element 12 detected absent
xx62 Element 13 detected absent
xx63 Element 14 detected absent
xx 22 for MPU emulation
24 for HPU emulation
30 for HCU emulation
3.4.2 Temperature status request (item MQ)
Four bytes status information (B0 B1 B2 B3) with the following meaning:
For decoding of the status bytes, refer to the ASCII table in appendix A.
Status byte 0:
Contains the characters ‘0’ ÷ 'D', indicating the highest submersed element of the MRT. At start up this is: ‘I’.
Status byte 1:
Status byte 2:
Bit 0: general temperature fail Bit 0: last valid level used
1: fail in average product temperature 1: manual level used
2: fail in average gas temperature 2: 0
3: level exceeds lowest element 3: 0
4: level exceeds highest element 4: 0
5: element fail (one or more elements defect) 5: 0
6: 1 6: 1
7: 0 7: 0
Status byte 3:
Bit 0: no previous store command
1: alternative (lower) element selected
2÷5: 0
6: 1
7: 0
Note:
Only the bits which are set to ‘1’ have an active status.
