F50F DUCT MOUNTED ELECTRONIC AIR CLEANER
68-0137—5
2
SPECIFICATIONS
IMPORTANT
The specifications given in this publication do not
include normal manufacturing tolerances.
Therefore, this unit may not exactly match the listed
specifications. This product is tested and calibrated
under closely controlled conditions, and some
minor differences in performance can be expected if
those conditions are changed.
Model:
Electronic Air Cleaner: Includes cabinet, access door, solid
state power supply, one or two electronic cell(s) and one or
two prefilter(s).
Electrical Ratings:
Voltage and Frequency: Models available for 120V, 60 Hz;
220/240V, 50 Hz; and 240V, 60 Hz. Specify when
ordering. Two cell 120V, 60 Hz models can be
converted in the field to 240V, 60 Hz or 220/240V,
50 Hz with the 203365A Conversion Kit.
Power Consumption:
One cell models: 22W maximum.
Two cell models: 36W maximum.
Current Draw: See Table 1.
Ionizer Voltage: 8150 Vdc.
Collector Voltage: 4075 Vdc.
Capacity, Efficiency, Pressure Drop:
See Fig. 1.
Temperature Ratings:
Operating Ambient: 40° to 125°F (4° to 52°C).
Temperature of Airflow Through Cells: 40° to 125°F
(4° to 52°C).
Maximum Cell Washing Temperature: 220°F (140°C).
Storage and Shipping Ambient: Minus 40°F to plus 140°F
(minus 40°C to plus 60°C).
Mounting:
Mounts in the return air duct of a forced air heating, cooling,
or ventilating system. Mount upstream from the atomizing
humidifier. See the Planning the Installation section.
Table 1. Current Draw.
Max. Current (A)
Size
No. 220/
in. mm
Cells
120V
240V
16 x 20 406 x 508 2 0.4 0.2
16 x 25 406 x 635 2 0.4 0.2
20 x 12-1/2 508 x 318 1 0.4 0.2
20 x 20 508 x 508 2 0.4 0.2
20 x 25 508 x 635 2 0.4 0.2
Table 2. Shipping and Installation Weight.
ORDERING INFORMATION
When purchasing replacement and modernization products from your TRADELINE® wholesaler or distributor, refer to the
TRADELINE® Catalog or price sheets for complete ordering number, or specify
1. Order number.
2. Voltage and frequency.
3. Dimensions: 16 x 20, 16 x 25, 20 x 12-1/2, 20 x 20, or 20 x 25 in. (406 x 508, 406 x 635, 508 x 318, 508 x 508, or
508 x 635 mm).
4. Conversion kit for changing two cell 120V, 60 Hz models to 240V, 60 Hz or 220/240V, 50 Hz.
5. W8600F Air Cleaner Monitor, if desired.
If you have additional questions, need further information, or would like to comment on our products or services, please write
or phone:
1. Your local Home and Building Control Sales Office (check white pages of your phone directory).
2. Home and Building Control Customer Logistics
Honeywell Inc., 1985 Douglas Drive North
Minneapolis, Minnesota 55422-4386
In Canada—Honeywell Limited/Honeywell Limitée, 35 Dynamic Drive, Scarborough, Ontario M1V4Z9.
International Sales and Service Offices in all principal cities of the world. Manufacturing in Australia, Canada, Finland, France,
Germany, Japan, Mexico, Netherlands, Spain, Taiwan, United Kingdom, U.S.A.
Weight
16 x 20 in.
(406 x 508 mm)
16 x 25 in.
(406 x 635 mm)
20 x 12-1/2 in.
(508 x 318 mm)
20 x 20 in.
(508 x 508 mm)
20 x 25 in.
(508 x 635 mm)
lb kg lb kg lb kg lb kg lb kg
Electronic Cell (Each) 5 2.25 6 2.7 7-1/2 3.4 6-3/16 2.8 7-1/2 3.4
Shipping Weight 30 13.6 33 15.0 25 11.3 33 15.0 38 17.2
Installed Weight
(Cells Included)
26 11.6 28 12.7 21 9.5 29 13.2 33 15.0
