F50F DUCT MOUNTED ELECTRONIC AIR CLEANER
68-0137—5
18
Nominal Return Air Opening
No. Description
16 x 20 in.
(406 x 508 mm)
16 x 25 in.
(406 x 635 mm)
20 x 12-1/2 in.
(508 x 318 mm)
20 x 20 in.
(508 x 508 mm)
20 x 25 in.
(508 x 635 mm)
1Access Door
includes No. 2
203306AB (1) 203306AB (1) 203305AB (1) 203305AB (1) 203305AB (1)
2 Test Button Assembly 137980A (1) 137980A (1) 137980A (1) 137980 (1) 137980A (1)
3Electronic Cell FC37A1114 (2) FC37A1130 (2) FC37A106 (1) FC37A1049
(2)
FC37A1064
(2)
4Cell Handle 137266 (2) 137266 (2) 137266 (1) 137266 (1) 137266 (2)
5Prefilter 209989 (2) 203371 (2) 203372 (1) 203373(2) 203372 (2)
6Cell Key 136518 (1) 136518 (1) 136518 (1) 136518 (1) 136518 (1)
7Power Box Assembly
Includes No. 8-20,
120V, 60 Hz
208418E (1) 208417B (1) 208419A (1) 208418A (1) 208417A (1)
240V, 60 Hz N/A N/A 208419B (1) N/A N/A
8 Switch 203321 (1) 203321 (1) 203321 (1) 203321 (1) 203321 (1)
9Power Box Cover
and Label
203319A (1) 203318A (1) 203320A (1) 203319A (1) 203318A (1)
10 Power Supply,
120V, 60 Hz
208414G (1) 208414B (1) 208414C (1) 208414B (1) 208414A (1)
240V, 60 Hz N/A N/A 208415C (1) N/A N/A
11 Interlock Bracket and
Switch
4074ETG (1) 4074ETG (1) 4074ETG (1) 4074ETG (1) 4074ETG (1)
12 W8600 Terminal Strip Supplied with W8600F
13 Terminal Board
Assembly Front
203329B (1) 203329B (1) 203329D (1) 203329C (1) 203329B (1)
14 Terminal Board
Assembly Rear
203329A (1) 203329A (1) N/A 203329A (1) 203329A (1)
15 Barrier Plate 203331 (1) 203331 (1) 203331 (1) 203331 (1) 203331 (1)
16 Strain Relief 203852 (1) 203852 (1) 203852 (1) 203852 (1) 203852 (1)
17 Line Cord 4074ETD (1) 4074ETD (1) 4074ETD (1) 4074ETD (1) 4074ETD (1)
18 Hole Plug 203847 (1) 203847 (1) 203847 (1) 203847 (1) 203847 (1)
19 Neon Assembly 4074EYS (1) 4074EYS (1) 4074EYT (1) 4074EYS(1) 4074EYS (1)
20 Airflow Switch 4074ETH (1) 4074ETH (1) 4074ETJ (1) 4074ETH (1) 4074ETH (1)
21 FC37A Bag Assembly
for cell repair. Contains
2 Connector Clips,
1 Terminal Board and
Instructions.
4074EHG 4074EHG 4074EHG 4074EHG 4074EHG
(#) = Quantity required per unit N/A = Not available as merchandized part.
REPLACEMENT PARTS/EXPLODED VIEW
