Wiring Instructions
The wires between the TP800 units must be no longer than 30 metres in total. The wiring from the Audio
Terminal Board to the TP800 speaker-mic is as follows:
AUDIO TERMINAL
BOARD
TP800
ECT ECOUT
RML RML
CMD CMD
NC NOT USED
VS+ VS+
VS- VS-
1. Wire the TP800 to the Audio Terminal Board as per the above table.
2. Finally secure the TP800 back plate to the wall through the elongated attachment holes.
3. Attach the TP800 front cover to the back plate by locating the bottom slot into the locating boss
and then snapping shut. Attach the screw to the top.
Operation of 2-Way Audio
Communication Modes
Two types of audio communication are possible: Listen-in (after alarm) or Dial-in.
Listen-in
In this mode, the panel will stay on-line for 30 seconds after sending an alarm signal to the ARC to allow
the operator to listen to the audio on site. The operation is controlled by the remote DTMF telephone and
is as follows:
1. Press the * then 6 keys to start listen-in.
2. Use the 0 and 1 keys to toggle between listen and talk modes (0 = listen, 1 = talk).
3. To end the call, press the * then # keys.
4. The call ends with three beeps.
Dial-in
In this mode, a user can dial into the alarm system from a DTMF telephone and type in a special PIN
code (controlled in Menu 42, User 99). This will allow the user to listen to the audio on site, and talk to
the site. The operation is controlled by the remote telephone and is as follows:
1. Dial in to either the PSTN number or the GSM audio number.
2. The panel answers after the number of rings set up in Menu 56.1.09.
3. Wait for a long tone then enter the PIN code to start listening.
4. Use the 0 and 1 keys to toggle between listen and talk modes (0 = listen, 1 = talk).
5. To end the call, press the * then # keys.
6. The call ends with three beeps.
In both modes, if no commands are detected within 2 minutes the call will be timed out and hung up. If
the remote user hangs up without using * and # then it can take up to 2 minutes before the call times out
at the panel end.
II1-0084 Rev 1.0
