Galaxy 3 Series Programming Manual
140
6 = Int RS232 Port
56 - Communications (cont’d)
Figure 9. Internal RS232 Programming structure
The Galaxy 3 Series supports an on-board RS232 serial port. This ports is:
• Programmable independently from the panel.
• Speed configurable from 300 to 56K bps (or highest practical speed).
• Able to configure data length, parity and stop bits.
• Supervised (optional via programming).
The RS232 port is configurable to support:
• Connection to a PC.
• Connection to a serial modem.
• Connection to 3
rd
party communication modules.
• Connection to serial printers.
• Connection to serial wireless transmitters.
6 = Int RS232 Port
1 = Mode
1 = Printer
2 = Direct
3 = Modem
1 = Telephone No.
2 = Dial Type
1 = Tone
2 = Pulse
2 = Format
1 = SIA 0 (0-3) 1 = Trigger Events
1 = Status
2 = Groups
2 = Microtech
1 = Trigger Events
1 = Status
2 = Groups
3 = Account No.
6 digit Max.
4 = Comms Setup
3 = Init String
1 = Baud Rate
2 = Data Bits
3 = Stop Bits
4 = Parity
1 = No Parity
2 = Odd Parity
3 = Even Parity
4 = Storage Mode
To Next Page
