Galaxy Flex Installer Manual Program Outputs [53]
123
Output Functions
This table shows all the outputs and the zone functions and conditions that result in their
activation.
Zone Function
Output Functions
Bells Strobe PA Intruder Tamper Reset Switch
DC
Set Spare Ready Security AC Fail Batt Low
01 02 03 04 05 07 08 09 11 12 13 14 15
01 Final S S – S T X – – – A – – –
02 Exit S S – S T – – – – A – – –
03 Intruder S S – S T – – – – A – – –
05 Security S S – S T – – – – A A – –
07 Entry S S – S T – – – – A – – –
08 Push Set – – – – T X – – – – – – –
09 Keyswitch – – – – T X X S – – – – –
10 Secure Final S S – S T X – – – A U – –
11 Part Final S S – S T X – – – A – – –
12 Part Entry S S – S T – – – – A – – –
13 PA A A A – T – – – – A – – –
14 PA Silent – – A – T – – – – A – – –
15 PA Delay A A A – T – – – – A – – –
16 PA Delay Silent – – A – T – – – – A – – –
18 Spare – – – – T – – – – – – – –
19 Fire A A – – T – – – – – – – –
20 Tamper S S – S A – – – – A – – –
22 Beam Pair S S – S T – – – – A – – –
23 Battery Low – – – – T – – – – – – – U
24 Line Fail – – – – T – – – – – – – –
25 AC Fail – – – – T – – – – – – A –
26 Log – – – – T – – – – A – – –
28 Video S S – S T – – – – A – – –
29 Video Exit S S – S T – – – – A – – –
32 Set Log – – – – T – – – – – – – –
33 Custom-A ? ? ? ? ?T ? ? ? ? ? ? ? ?
34 Custom-B ? ? ? ? ?T ? ? ? ? ? ? ? ?
39 Keyswitch Reset – – – – T X – – – – – – –
40 Bell fail – – – – – – – – – – – – –
41 Intr Low S S – S T – – – – A – – –
42 Intr High S S – S T – – – – A – – –
43 PSU Fault – – – – T – – – – – – – –
44 Fault – – – – T – – – – – – – –
45 Entry 2 S S - S T - -- - - A - - -
53 Monitor - - - - - - - - - - - - -
Key:
S Activates when system is Set ? Activation dependant on system programming
P Activates when system is Part Set X Activates during Exit Time
U Unset E Activates during Entry Time
A Activated in any condition L Switches output off if linked to destination output
– No effect T Activates if zone resistance is less than value for
tamper s/c or greater than value for tamper o/c
O Activates when zone is omitted
