Program Outputs [53] Galaxy Flex Installer Manual
124
Zone Function
Output Functions
Fire Horn E/E
Horn
Part
Set
Confirm
Line
Fail
Video Comm
Fail
DLYD
Fire
No
Re-arm
Timer-A
Timer-B
16 17 18 19 20 21 22 23 27 28 29 30
01 Final – S SXE – - – S – – S – –
02 Exit – S SXE – S – S – – S – –
03 Intruder – S SXE – S – S – – S – –
05 Security – S A – – – S – – S – –
07 Entry – S SXE – - – S – – S – –
08 Push Set – – X – – – – – – – – –
09 Keyswitch – – – X – – – – – – – –
10 Secure Final – A A X S – S – – S – –
11 Part Final – A SXE X S – S – – S – –
12 Part Entry – A XE – S – S – – S – –
13 PA – A – – – – – – – A – –
14 PA Silent – – – – – – – – – – – –
15 PA Delay – A A – – – – – – A – –
16 PA Delay Silent – – – – – – – – – – – –
18 Spare – – – – – – – – – – – –
19 Fire A A A – – – V – A A – –
20 Tamper – A A – – – S – – S – –
22 Beam Pair – S SXE – – – S – – S – –
23 Battery Low – – – – – – – – – – – –
24 Line Fail – – U – – A – – – – – –
25 AC Fail – – – – – – – – – – – –
26 Log – – – – – – – – – – – –
28 Video – S SXE – S – S – – S – –
29 Video Exit – S SXE – S – S – – S – –
32 Set Log – – – – – – – – – – – –
33 Custom-A ? ? ? ? ? ? ? ? ? ? ? ?
34 Custom-B ? ? ? ? ? ? ? ? ? ? ? ?
39 Keyswitch Reset – – – – – – – – – – – –
40 Bell fail – – – – – – – – – – – –
41 Intr Low – S SXE – S – S – – S – –
42 Intr High – S SXE – S – S – – S – –
43 PSU Fault – – – – – – – – – – – –
44 Fault – – – – – – – – – – – –
45 Entry 2 - S SXE - - - S - - S - -
53 Monitor - - - - - - - - - - - -
Key:
S Activates when system is Set ? Activation dependant on system programming
P Activates when system is Part Set X Activates during Exit Time
U Unset E Activates during Entry Time
A Activated in any condition L Switches output off if linked to destination output
– No effect T Activates if zone resistance is less than value for
tamper s/c or greater than value for tamper o/c
O Activates when zone is omitted
