Honeywell Galaxy Flex 100 V3 User Manual

Galaxy Flex Installer Manual Program Outputs [53]
125
Zone Function
Output Functions
Zone
Omit
Custom
A
Custom
B
Reset
RQD
Fail
Set
Duress Illegal
Code
Abort Unset Set
Late
U/S
Early
Pre-
Warn
Autoset Link
A-E
32 34 35 37 40 41 42 44 45 46 47 48 49 51-55
01 Final O – – S? – – – – – – – ? – ?
02 Exit O – – S? – – – – – – – ? – ?
03 Intruder O – – S? – – – – – – – ? – ?
05 Security O – – S? – – – – – – – ? – ?
07 Entry O – – S? – – – – – – – ? – ?
08 Push Set O – – – – – – – – U? S? – – ?
09 Keyswitch O – – – UX – – – U – – ? – ?
10 Secure Final O – – – – – – – – – – ? – ?
11 Part Final O – – – – – – – – – – ? – ?
12 Part Entry O – – – – – – – – – – ? – ?
13 PA O – – – – – – – – – – ? – ?
14 PA Silent O – – – – – – – – – – ? – ?
15 PA Delay O – – – – – – – – – – ? – ?
16 PA Delay Silent O – – – – – – – – – – ? – ?
18 Spare – – – – – – – – – – – ? – ?
19 Fire O – – A? – – – – – – – ? – ?
20 Tamper O – – A? – – – – – – – ? – ?
22 Beam Pair O – – – – – – – – – – ? – ?
23 Battery Low O – – – – – – – – – – ? – ?
24 Line Fail O – – – – – – – – – – ? – ?
25 AC Fail O – – – – – – – – – – ? – ?
26 Log O – – – – – – – – – – ? – ?
28 Video O – – S? – – – – – – – ? – ?
29 Video Exit O – – S? – – – – – – – ? – ?
32 Set Log O – – – – – – – – – – ? – ?
33 Custom-A O? ? ? ? ? ? ? ? ? ? ? ? ? ?
34 Custom-B O? ? ? ? ? ? ? ? ? ? ? ? ? ?
39 Keyswitch Reset O – – – – – – – – – – ? – ?
40 Bell Fail – – – – – – – – – – – – – –
41 Intr Low O – – S? – – – – – – – ? – ?
42 Intr High O – – S? – – – – – – – ? – ?
43 PSU Fault O – – – – – – – – – – ? – ?
44 Fault O – – – – – – – – – – ? – ?
45 Entry 2 O - - S? - - - - - - - ? - ?
53 Monitor - - - - - - - - - - - - - ?
Key:
S Activates when system is Set ? Activation dependant on system programming
P Activates when system is Part Set X Activates during Exit Time
U Unset E Activates during Entry Time
A Activated in any condition L Switches output off if linked to destination output
– No effect T Activates if zone resistance is less than value for
tamper s/c or greater than value for tamper o/c
O Activates when zone is omitted
