Program Outputs [53] Galaxy Flex Installer Manual
126
Output Functions
RF
Jam
RF
Super
Bell Fail Fault Bell
Test
Comms
Test
Listen–in
Fire
Reset
Confirmed
Fire Alarm
66 67 68 76 77 78 81 82 83
01 Final – – – – – – – - -
02 Exit – – – – – – – - -
03 Intruder – – – – – – ? - S
05 Security – – – – – – – - -
07 Entry – – – – – – – - -
08 Push Set – – – – – – – - -
09 Keyswitch – – – – – – – - -
10 Secure Final – – – – – – – - -
11 Part Final – – – – – – – - -
12 Part Entry – – – – – – – - -
13 PA – – – – – – ? - -
14 PA Silent – – – – – – ? - -
15 PA Delay – – – – – – ? - -
16 PA Delay Silent – – – – – – ? - -
18 Spare – – – – – – – - -
19 Fire – – – – – – ? - A
20 Tamper – – – – – – – - -
22 Beam Pair – – – – – – – - -
23 Battery Low – – – A – – – - -
24 Line Fail – – – A – – – - -
25 AC Fail – – – A – – – - -
26 Log – – – – – – – - -
28 Video – – – – – – – - -
29 Video Exit – – – – – – – - -
32 Set Log – – – – – – – - -
33 Custom-A ? ? ? – – – – - -
34 Custom-B ? ? ? – – – – - -
39 Keyswitch Reset – – – – – – – - -
40 Bell Fail – – A A – – – - -
41 Intr Low – – – – – – ? - -
42 Intr High – – – – – – ? - -
43 PSU Fault – – – A – – – - -
44 Fault – – – A – – – - -
45 Entry 2 - - - - - - - - -
53 Monitor - - - - - - - - -
Key:
S Activates when system is Set ? Activation dependant on system programming
P Activates when system is Part Set X Activates during Exit Time
U Unset E Activates during Entry Time
A Activated in any condition L Switches output off if linked to destination output
– No effect T Activates if zone resistance is less than value for
tamper s/c or greater than value for tamper o/c
O Activates when zone is omitted
