33
Vigilon fire alarm system
How to edit an Input/output line label
NA
This operation is not applicable for a Network Node.
Each input / output (IO) line of an interface unit can be given a
label and a previously entered label can be modifi ed. To edit an IO
line label you will need to know the IO line number, interface device
number and the loop number it is connected to. You can fi nd this
information in the site specifi c documentation, held by the person
responsible for the fi re alarm system.
a. Press the MENU ON/OFF button.
b. Press the F2 button to select [Set Up].
c. Press the F4 button to select [UserCode]. Notice a message on
the display ‘Enter access code’, followed by a fl ashing cursor.
Use the keypad to input your PIN and then press Enter button.
d. Press the F4 button once to select <etc>.
e. Press the F1 button to select [Modify]. Notice ‘Modify’ appears
on the display.
f. Press the F1 button to select [Label]. Notice ‘Label’ appears on
the display.
g. Press the F2 button to select [IO Line]. Notice ‘IO Line’ followed
by a fl ashing cursor on the display. Using the keypad enter an
input/output number from a range 1 to 4.
h. Press the F3 button to select [Device]. Notice ‘Device’ followed
by a fl ashing cursor appears on the display. Use the keypad to
input a Device number from the range 1 to 200.
i. Press the F2 button to select [Loop]. Notice ‘Loop’ followed by
a fl ashing cursor on the display. Use the keypad to input a loop
number 1 or 2.
j. Press the F2 button to select [Enter]. Notice the
previous label appears on the display with a fl ashing
fi rst character to prompt you to edit a label. If there is
no label then the line is blank.
k. Using the keypad enter a label of up to 32 characters
in length and then press the Enter button.
