Honeywell HDZ302DE User Manual

Configuring Recording Settings | 81
800-22456 - A - 04/2017
Configuring Storage Paths
On the Path tab, you can specify where you want recorded video and snapshots—whether
scheduled or triggered by a motion detection or alarm event—to be saved: to a local SD card,
to an FTP server, or to an NAS disk.
Select which recorded events you want to save and where you want to save them, then click
Save to apply the settings.
Note Only one network storage option can be used at a time. FTP and NAS cannot
be used together.
Configuring the Local SD Card for Storage
If the camera has a microSD card installed, the Local tab displays the microSD card details.
You can set up the installed microSD card for read-only, read-and-write, or hot swap
operation by clicking the corresponding button.
• Read Only: Data on card can be displayed but not modified.
• Read & Write: Data on card can be displayed and modified.
• Hot Swap: Card can be inserted or removed without turning off the camera.
If you want to erase all of the data on the microSD card, click Format. A confirmation
message appears. Click OK to continue. The card is formatted and the camera reboots.

Honeywell HDZ302DE Specifications

General

Series	HDZ
Image Sensor	1/2.8" Progressive Scan CMOS
Scanning System	Progressive
IR On/Off Control	Auto/Manual
IR LEDs	6
Focus Control	Auto/Manual
Gain Control	Auto/Manual
Digital Zoom	16x
Streaming Method	Unicast/Multicast
Certifications	CE, FCC, UL
Ingress Protection	IP66
Vandal Resistance	IK10
Night Vision	Yes
Two-Way Audio	Yes
Weather Resistance	Yes
Effective Pixels	1920 (H) x 1080 (V)
Electronic Shutter Speed	1/1 s to 1/30, 000 s
Minimum Illumination	0 Lux with IR
Power-off Memory	Yes
Protocol	HTTP, HTTPS, DHCP, DNS, DDNS, RTP, RTSP, PPPoE, SMTP, NTP, UPnP, SNMP, 802.1x, Qos
Video Compression	H.264
Streaming Capability	Triple-streaming
Resolution	1920 x 1080
Bit Rate Control	CBR / VBR
Day/Night	Auto (ICR), Color, B/W
BLC Mode	BLC/HLC/WDR
White Balance	Auto / Manual / Outdoor / Indoor / Sodium Lamp
Noise Reduction	3D DNR
Motion Detection	Support
Region of Interest	4 zones
Electronic Image Stabilization (EIS)	Yes
Defog	Yes
Flip	Yes
Privacy Masking	4 zones
Audio Compression	G.711
Network	10/100Base-T Ethernet
Interoperability	ONVIF Profile S, PSIA, CGI
Edge Storage	Micro SD card
Web Viewer	IE, Chrome, Firefox, Safari
Smart Phone	iOS, Android
Power Supply	DC12V / PoE
Power Source	24 VAC & PoE+ (802.3at)
Storage	Micro SD card
Connectivity	10/100Base-T Ethernet
Bit Rate	32 Kbps to 16384 Kbps
