Honeywell Heating Controller SDC - Page 27

SDC / DHC Operation
EN2H-0220GE51 R1111 27
Operating overview
Average/current outside
temperature value
Outside temperature
min. to max. (0:00 to 24:00 hours)
Heat generator temperature
setpoint/actual value
Hot-water temperature
setpoint/actual value
Flow temperature
setpoint/actual value
Flow temp of mixed heating circuit 1
setpoint/actual value
Variable input 1
setpoint/actual value
Operating hours
Activations of heat generator
Program/operating mode
direct heating circuit/pump status
Program/operating mode
mixed heating circuit 1/pump status
Actuator of
mixed heating circuit 1/status
Program/operating mode
mixed heating circuit 2/pump status
Actuator of
mixed heating circuit 2/status
Program/operating mode
hot-water circuit/pump status
Heat generator
status
Direct heating circuit
pump function/status
Variable output 1
function/operating state
Turn input button to the left Turn input button to the right
Press button
Variable output 2
function/operating state
Flow temp of mixed heating circuit 2
setpoint/actual value
Variable input 2
setpoint/actual value
Variable input 2
setpoint/actual value
