Page #3 background imageLoading...
Page #3 background image
© INNCOM by Honeywell - 3 -
22 November 2013
CONFIDENTIAL
Training Bulletin 01
Document or product name here
22 November 2013
CONFIDENTIAL
Training Bulletin 01
Document or product name here
22 November 2013
CONFIDENTIAL
Training Bulletin 01
Document or product name here
2. Thermostat wire connections:
HVAC INTERFACE LOW VOLTAGE INTERFACE
Connection
Color
Function
Connection
Color
FC1
Green
EARTH GROUND
FC11
Brown
DC GROUND
FC2
Red
24 VAC POWER
FC12
Red
DC OUT
FC3
Black
24 VAC COMMON
FC13
Orange
S5 BUS
FC4
Blue
HIGH FAN RELAY
FC14
Yellow
INPUT 1
FC5
Brown
MED FAN RELAY/ HEAT RELAY(STAGE 2)
FC15
Green
INPUT 2
FC6
Yellow
COMPRESSOR CONTACTOR
FC7
White
HEAT RELAY(STAGE 1)/ REVERSING VALVE
FC8
Grey
24 VAC VALVE POWER
FC9
Violet
24 VAC FAN POWER
FC10
Orange
LOW FAN RELAY
FIELD SIDE INTERFACE
Connection
Color
Function
FC16
Orange
10K NTC (REMOTE THERMISTOR INPUT)
FC17
Red
GROUND
FC18
Brown
NO CONNECTION
FC19
Orange
10K NTC (REMOTE THERMISTOR INPUT)
FC20
Red
GROUND
FC21
Brown
NO CONNECTION
FC22
Orange
ANALOG OUTPUT-2
FC23
Red
ANALOG OUTPUT-1
FC24
Brown
GROUND
