2. Thermostat wire connections:
HVAC INTERFACE LOW VOLTAGE INTERFACE
Connection
Color
Function
Connection
Function
FC1
Green
EARTH GROUND
FC11
Brown
DC GROUND
FC2
Black
LINE
FC12
Red
DC OUT
FC3
White
NEUTRAL
FC13
Orange
S5 BUS
FC4
Yellow
HIGH FAN RELAY
FC14
Yellow
INPUT 1
FC5
Orange
MED FAN RELAY/ HEAT RELAY(STAGE 2)
FC15
Green
INPUT 2
FC6
Red
COMPRESSOR CONTACTOR
FC7
Brown
HEAT RELAY(STAGE 1)/ REVERSING VALVE
FC8
Grey
VALVE POWER
FC9
Violet
FAN POWER
FC10
Blue
LOW FAN RELAY
FIELD SIDE INTERFACE
Connection
Color
Function
FC16
Orange
10K NTC (REMOTE THERMISTOR INPUT)
FC17
Red
GROUND
FC18
Brown
NO CONNECTION
FC19
Orange
10K NTC (REMOTE THERMISTOR INPUT)
FC20
Red
GROUND
FC21
Brown
NO CONNECTION
FC22
Orange
ANALOG OUTPUT-2
FC23
Red
ANALOG OUTPUT-1
FC24
Brown
GROUND
