CV41 Vehicle Mount Computer (Windows CE) User Guide 49
Wireless LAN
Bluetooth
Default Configuration
The following tables list the default values of the configuration settings supported on
the computer. If you restore the computer to factory default settings, the computer uses
these values.
The settings are grouped by function and reflect the organization of Intermec Settings.
Not all of the configuration settings are listed in this appendix. For detailed information
on most of the settings, see the Intermec Settings Command Reference Manual.
Keypad Backlit 64 QWERTY keyboard with number pad and 10
function keys. Universal keyboard overlay legend and
supports VT220, 3270, 5250. All keys (except modifiers and
the power button) are mappable.
Processor Intel Atom Z530 at 1.6 GHz
Memory 1 GB total mappable memory with 512 MB as system
memory in Windows CE.
Integrated radio 802.11a/b/g
Interfaces USB 2.0 host port, USB 1.1 client port, two RS-232 COM
ports, a CANBUS/audio port, DC power input and ignition
input, and RF antenna ports for Wi-Fi, WWAN, and GPS.
Antennas Dual internal antennas or optional external antennas
Removable storage Secure Digital
Operating system Microsoft Windows CE 6.0
Data rates Supports all 802.11a/b/g data rates.
Wireless frequencies
(varies by domain)
• 2.4 to 2.4895 GHz IEEE 802.11b/802.11g DSSS OFDM
• 5.15 to 5.82 GHz IEEE 802.11a DSSS OFDM
RF data rates 1, 2, 5.5, 6, 9, 11, 12, 18, 14, 36, 48, 54 Mbps
RF power level 64 mW (18 dBm)
Channels FCC: 1-11, 36, 40, 44, 48, 149, 153, 157, 161
ETSI: 1-13, 36, 40, 44, 48
Security WPA, WPA2, 802.1x (EAP-TLS, TTLS, LEAP, PEAP, EAP-
FAST), WEP
Cisco compatibility CCX v4 certified
Data rates Up to 3.0 Mbits over the air
Connection 10 m (32.8 ft) line of sight
Bluetooth version 2.0 + EDR
Operating frequency 2.402-2.480 GHz
QDID B013455
