Honeywell IRD 1020.1 User Manual

4
ORDERING INFORMATION
ITEM DESIGNATION ITEM NO.
Flame sensor Flicker detector IRD 1020.1 side-on right blue 230V 16531
Flicker detector IRD 1020.1 side-on right white 230V 1653104
optional Flicker detector IRD 1020.1 end-on viewing blue 230V 16532
Flicker detector IRD 1020.1 D end-on viewing blue 230V 16552
Flicker detector IRD 1020.1 end-on viewing white 230V 1653204
Flicker detector IRD 1020.1 end-on viewing blue 115V 16572
Flicker detector IRD 1020.1 side-on left blue 230V 16533
Mounting flange Flange M93 230V 59093
Sensor cable Plug type, 3-wire, 0.6 m with tag wire ends 7236001
The above ordering information refers to the standard version.
Special versions are also included in our product range. Specifications subject to change without notice.
FLICKER DETECTOR IRD 1020.1
VARIANTS
35
3
26
4.5
15.1
48
ø20.5
4
17
14
104
29
50 44
ø13.5
21.8
HOLDER M93
Satronic
IRD 1020.1
Satronic
IRD 1020.1
Satronic
IRD 1020.1
Item no.
Light entrance from right blue 16531 230 Volt
white 1653104 230 Volt
End-on light entrance blue 16532 230 Volt
white 1653204 230 Volt
blue 16572 115 Volt
blue 16552 230 Volt
(1020.1 D version)
Light entrance from left blue 16533 230 Volt
