Honeywell LR-HWLV-HVAC

Installation Guide
P/N 041-338 Rev. A 2 69-2655EFS—01
M33026
Wallplate installation
1. Separate wallplate from thermostat.
2. Mount wallplate as shown below.
Drill3/16in(5mm)holesfordrywall.
Drill7/32in(6mm)holesforplaster.
Wallanchors
Wirehole Mounting screws
Grasptopandbottomofwallplate
and pull to remove from thermostat.
+
+
+
M29480
RF Device Placement
• Thethermostatmustbewithin30ft(9m)ofanRFsignalrepeater.
CAUTION
Thermostat should be installed by a climate control specialist to avoid damage to the
equipment.
