Lynx Plus Series Installation and Setup Guide
- 23 -
Data Field Descriptions
Field ✻37-✻39: Field ✻37 is not available on the LynxSIA Plus control. Fields ✻38 and ✻39 are used to program different
features in the Lynx Plus and LynxSIA Plus controls. Please be sure that you use the correct field for the control being
installed.
37
3737
37
EX
EXEX
EXI
II
IT
T T
T SND
SNDSND
SND/
//
/Q
QQ
QK
K K
K EXIT
EXITEXIT
EXIT
Audible Exit Warning/Quick Exit
Audible Exit Warning: Sound consists of slow continuous beeps until last 5 seconds,
when it changes to fast beeps. The warning sound will end at the termination of exit
delay.
Quick Exit: If enabled, the user can restart the exit delay time after arming in STAY
mode by entering the User Code and pressing the STAY key, or by pressing the STAY
key if Quick Arm is enabled. This avoids having the user disarm then re-arm the
system after allowing someone to enter or exit.
SELECTIONS
Exit Warning Quick Exit
0 = no exit warning sound 0 = no quick exit
1 = provide exit warning sound when armed AWAY 1 = allow quick exit
38
38 38
38
CONF
CONF CONF
CONF ARM
ARMARM
ARMING
INGING
ING DING
DINGDING
DING
Confirmation of Arming Ding
Lynx Plus - Confirmation of arming is provided by a 1/2 second external sounder “ding”
that sounds when closing report is sent, or at the end of exit delay. If Option 2 is selected
the external sounder “ding” occurs immediately after the system receives the RF
transmission.
LynxSIA Plus - Confirmation of arming is provided by a 1/2 second external sounder
“ding”. The ding only sounds when control is Armed Away or disarmed after being Armed
Away.
If Option 1 is selected, confirmation of arming is provided by a 1/2 second sounder
“ding” that sounds when closing report is sent, or at the end of exit delay. If Option 2 is
selected the external sounder “ding” occurs immediately after arming from an RF
keypad.
Note: If LynxSIA Plus is armed by RF button (key fob), a confirmation ding occurs
immediately after arming regardless of field *38 settings. If control is disarmed by RF
button, an additional disarming confirmation ding is provided. The ding occurs
immediately after disarming and is longer than arming confirmation ding.
Lynx Plus SELECTIONS
0 = no ding
1 = confirmation ding after arming
system
2 = confirmation ding after arming from
RF button or RF keypad only
LynxSIA Plus SELECTIONS
0 = no arming confirmation ding after arming
system by Lynx Plus keypad or RF
keypad
1 = arming confirmation ding after arming
system by Lynx Plus keypad or RF
keypad
2 = arming confirmation ding after arming
from RF keypad only
39
39 39
39
PWR
PWR PWR
PWR UP
UP UP
UP PRV
PRV PRV
PRV STATE
STATESTATE
STATE
(This field applies only to the
Lynx Plus control)
Power Up In Previous State (This field applies only to the Lynx Plus control)
When the system powers up armed, an alarm will occur 1 minute after arming if a zone
is faulted, and any bypassed zones will be unbypassed.
Note: If the previous state was Armed Away or Stay, the system will not respond to sensor
changes for 1 minute. This allows time for sensors such as PIRs to stabilize.
UL installations: must be 1 (power up in previous state)
Lynx Plus SELECTIONS
0 = always power up in a disarmed state
1 = assume the system status prior to power-down
