LYNX Touch Installation and Setup Guide
- 30 -
Programming the Control
SCREEN ACTION
Device Type
Device Type
Select “Device Type”. The system displays the following options (dependant upon the Device
Type selection):
New Door
Window Motion Sensor
Glass Break Smoke Detector
Heat Sensor Carbon Mono. Det.
Use the down T arrow to scroll to the next page of options:
Temperature Flood
Environmental Medical
Fire Police
Garage Door Other
Response Type
Not Used
Response Type
1. Select “Response Type”. The system displays the specific options, which are dependant
upon the Device Type that was selected for the zone. Use the down T arrow to scroll to the
next page of options. Use the S arrow to return to the previous page.
Not Used Entry Exit 1
Entry Exit 2 Perimeter
Interior Follower Trouble
24 Hour Silent 24 Hour Audible
24 Hour Auxiliary Fire No Verification
Interior With Delay Monitor
Carbon Monoxide Garage
Arm Stay Arm Away
Disarm No Response
Silent Burglary Resident Monitor
Resident Response General Monitor
General Response Fire With Verification
Day/Night Garage Monitor
2. Select the desired Response Type and select “Save”. The system will return to the Zone
screen.
Note: For threshold monitoring to be configurable on the LYNX Touch Z-wave thermostat screen, the
respective zones will first need to be assigned with a response type in zone programming. The
recommended response type is Trouble.
Alarm Report
Yes
Alarm Report
Note: This field is for Alarms. If Response Type “Trouble” is set up and Alarm Report is set to
“No” the system will still report if Report Alarms was enabled in the Reporter
programming.
Select “Report” to toggle between “No” or “Yes”. Select “Save”.
Chime
No
Chime
Note: Chime only applies to entry/exit, perimeter and interior zone types.
Select “Chime” to toggle between “No” or “Yes”. Select “Save”.
Supervision
Supervised
Supervision
The system displays the applicable Supervision options based upon the Device Type that was
selected. Select “Supervision” to scroll between the following options:
Hardwire Zone
Normal Open
Normal Closed
End of Line
RF Zone
Supervised
Unsupervised
Temperature (Defaulted for Zones 80-85)
High Temp (Default selection for Zones 80, 82 and 84)
Low Temp (Default selection for Zones 81, 83 and 85)
After making a Supervision selection, select “Save”.
