Honeywell LYNX Touch Series User Manual

LYNX Touch Installation and Setup Guide
- 68 -
Zone Programming Default Values
Zone Assignment/Alarm Response Types for Configuration 1
Zone
Number
Loop
Number
Device Type Response Type Report Chime
Supervision/
Input Type
Zone Descriptor
1 --- New n/a Yes No EOLR n/a
2 2 Door Entry Exit 1 Yes Yes Supervised Front
3 2 Door Entry Exit 1 Yes Yes Supervised Back
4 2 Window Perimeter Yes Yes Supervised n/a
5 1 Motion Sensor Interior w/Delay Yes No Supervised n/a
46 1 New Not Used No Yes Supervised Main
47 1 New Not Used No Yes Supervised Main
48 1 New Not Used No Yes Supervised Main
49 3 4 Button Key Arm Away Yes No Button n/a
50 2 4 Button Key Disarm Yes No Button n/a
51 4 4 Button Key Arm Stay Yes No Button n/a
52 1 4 Button Key No Response no No Button n/a
53 3 4 Button Key Arm Away Yes No Button n/a
54 2 4 Button Key Disarm Yes No Button n/a
55 4 4 Button Key Arm Stay Yes No Button n/a
56 1 4 Button Key No Response no No Button n/a
80 n/a Temperature Not Used Yes No High Temp n/a
81 n/a Temperature Not Used Yes No Low Temp n/a
82 n/a Temperature Not Used Yes No High Temp n/a
83 n/a Temperature Not Used Yes No Low Temp n/a
84 n/a Temperature Not Used Yes No High Temp n/a
85 n/a Temperature Not Used Yes No Low Temp n/a
95 --- Fire Fire No Verification Yes No Panic Trigger n/a
96 --- Medical n/a Yes No Panic Trigger n/a
97 --- --- --- Yes No Cover Tamper n/a
99 --- Police 24-Hour Silent Yes No Panic Trigger n/a
NOTE: Zone 1 is a hardwire zone; Zone 2 to 48 are RF zones (Zones 46 to 48 are reserved for Garage Door Zones); Zone 92
is Duress; Zone 99 is keypad panic
Zone Assignment/Alarm Response Types for Configuration 2
Zone
Number
Loop
Number
Device Type Response Type Report Chime
Supervision/
Input Type
Zone Descriptor
1 --- New n/a Yes No EOLR n/a
2 2 Door Entry Exit 1 Yes Yes Supervised Front
3 2 Door Entry Exit 1 Yes Yes Supervised Back
4 2 Door Entry Exit 1 Yes Yes Supervised Garage
5 1 Motion Sensor Interior w/Delay Yes No Supervised n/a
6 1 Smoke Detector Fire No verification Yes No Supervised n/a
46 1 New Not Used No Yes Supervised Main
47 1 New Not Used No Yes Supervised Main
48 1 New Not Used No Yes Supervised Main
49 3 4 Button Key Arm Away Yes No Button n/a
50 2 4 Button Key Disarm Yes No Button n/a
51 4 4 Button Key Arm Stay Yes No Button n/a
52 1 4 Button Key No Response No No Button n/a
53 3 4 Button Key Arm Away Yes No Button n/a
54 2 4 Button Key Disarm Yes No Button n/a
55 4 4 Button Key Arm Stay Yes No Button n/a
56 1 4 Button Key No Response No No Button n/a
80 n/a Temperature Not Used Yes No High Temp n/a
81 n/a Temperature Not Used Yes No Low Temp n/a
82 n/a Temperature Not Used Yes No High Temp n/a
83 n/a Temperature Not Used Yes No Low Temp n/a
84 n/a Temperature Not Used Yes No High Temp n/a
85 n/a Temperature Not Used Yes No Low Temp n/a
95 --- Fire Fire No Verification Yes No Panic Trigger n/a
96 --- Medical 24-Hour Auxiliary Yes No Panic Trigger n/a
97 --- --- --- Yes No Cover Tamper n/a
99 --- Police 24-Hour Audible Yes No Panic Trigger n/a
NOTE: Zone 1 is a hardwire zone; Zone 2 to 48 are RF zones (Zones 46 to 48 are reserved for Garage Door Zones); Zone 92
is Duress; Zone 99 is keypad panic

Honeywell LYNX Touch Series Specifications

General

Zones	Up to 64 wireless zones
Integrated Camera	No
Voice Prompts	Yes
Encryption	Yes
Communication	Wi-Fi, Cellular
Backup Battery	Yes
Alarm Notifications	Yes
Siren	Built-in siren
Remote Access	Yes
Display	Color touchscreen
