Honeywell M7410E - Dimensions; Housing Type B Dimensions; Housing Type C Dimensions

M7410E SMALL MODULATING LINEAR VALVE ACTUATOR
Automation and Control Solutions
Honeywell GmbH
Böblinger Straße 17
D-71101 Schönaich
Phone: (49) 7031 63701
Fax: (49) 7031 637493
http://europe.hbc.honeywell.com
Subject to change without notice. Printed in Germany Manufacturing location certified to
EN0B-0097GE51 R1004
DIMENSIONS (MM)
49
100
60
58
Fig. 13. Housing type B
49
109
87
82
Fig. 14. Housing type C
