MCV2000 SERIES HYDRONIC VALVE
ENS5001R2 KO06 2005 2
Table 2. Model Assembly Guide
Model
(Assembly)
Model(Motor) Model(Valve)
Model
(Assembly)
Model(Motor) Model(Valve)
MCV2000AA MV2000AA MCV2010AA MV2000AA
MCV2000AH MV2000AH MCV2010AH MV2000AH
MCV2000AP
MC2000E
MV2000AP MCV2010AP
MC2010E
MV2000AP
MCV2000AV MC2000HE MV2000AV MCV2010AV MC2010HE MV2000AV
MCV2001AA MV2000AA MCV2011AA MV2000AA
MCV2001AH MV2000AH MCV2011AH MV2000AH
MCV2001AP
MC2001E
MV2000AP MCV2011AP
MC2011E
MV2000AP
MCV2001AV MC2001HE MV2000AV MCV2011AV MC2011HE MV2000AV
* Product Examples
- MC20xxE/HE : Actuator only, Egg crate with 15 actuators
- MV20xxAA/AH/AP/AV : Valve only, Egg crate with 40 valves(1/2”), 30 valves(3/4”), 21 valves(1”), 10 valves(1 1/4”)
* MC20 : Actuator family identifier
MCV2001AH
* xx00 : AC220V, SPST
* xx01 : AC220V, SPDT
* xx10 : AC110V, SPST
* xx11 : AC110V, SPDT
* E : 0.8Nm motor
* HE : 1.5Nm motor
* MV2000 : Valve family identifier
Table 3. Kv & Differential Pressure
Valve size Kv Max. operating differential pressure
1/2” 1.7 3.5 bar
3/4” 1.9 3.5 bar
1” 2.1 3.5 bar
1 1/4” 5.5 2.8 bar
Table 1. Model Selection Guide
* A : 1/2” valve
* H : 3/4” valve
* P : 1” valve
* V : 1 1/4” valve
with Int.(inlet) / Ext.(outlet) thread
* A : 2-way valve
* M : 3-way valve
MC20 01 E + MV2000 A H
* MCV2001AH = MC2001E + MV2000AH : AC220V, SPDT, 0.8Nm, 3/4
”
, 2
-
way valve
(with int.(inlet) / Ext.(outlet) thread & PT fitting)
