ML6984, ML7984 SERIES 4000 DIRECT COUPLED VALVE ACTUATORS
7 95C-10939—11
Fig. 13. ML7984 Wiring with Common Transformer,
Individual Controllers.
Fig. 14. ML7984 with Individual Transformers, Common
Controller.
B
R
W
R
WB
R
W
T6
T5
B
R
W
B
R
W
T6
T5
B
R
W
B
R
W
T6
T5
T6
T5
6
2 3
SINGLE
SOURCE
MODULATING
LIMIT
ML7984
2
3
ML7984
2 3
ML7984
24 VAC
OR
28 VDC
L1
L2
4
5
FUNCTION DIP SWITCH CONFIGURATION
1001
MECHANICAL SERIES 90
DIRECT ACTING
1011
MECHANICAL SERIES 90
REVERSE ACTING
ON (1)
OFF (0)
1 2 3 4
ON (1)
OFF (0)
1 2 3 4
1
POWER SUPPLY PROVIDES OVERLOAD PROTECTION AND
DISCONNECT MEANS.
2
ALLOW UP TO 0.5 AMPS FOR EACH DEVICE. ACTUATORS AND
CONTROLLER CAN SHARE SAME TRANSFORMER PROVIDING THE
VA RATING OF THE TRANSFORMER IS NOT EXCEEDED AND PROPER
PHASING IS OBSERVED. DO NOT MIX A.C. AND D.C. POWER SOURCES.
3
DO NOT MIX M984/6 OR MODUTROL MOTORS WITH THE ML7984 IN
THE SAME CIRCUITRY.
4
USE CONFIGURATION DIP SWITCHES TO SELECT DEVICE FUNCTIONS:
DIRECT ACTING FUNCTION (ACTUATOR STEM MOVES UPWARDS WITH
SIGNAL INCREASE) OR REVERSE ACTING FUNCTION (ACTUATOR
STEM MOVES DOWNWARDS WITH SIGNAL INCREASE).
5
TURN POWER OFF BEFORE SETTING ANY DIP SWITCHES. FOR
COMMON TRANSFORMER AND COMMON CONTROLLER APPLICATION,
PLEASE CONSULT THE FACTORY.
6
MAXIMUM RESISTANCE PER CONTROL CIRCUIT OF 280 OHM.
M25497A
B
R
W
T6
T5
B
R
W
B
R
W
T6
T5
B
R
W
T6
T5
T6
T5
2 3
ML7984
2 3
ML7984
2 3
ML7984
24 VAC
OR
28 VDC
L1
L2
24 VAC
L1
L2
T6
T5
OR
28 VDC
T6
T5
OR
28 VDC
L1
L2
24 VAC
1
2
1
2
1
2
4
SINGLE
SOURCE
RESISTOR SELECTION CHART
4
NO. OF
ACTUATORS
RESISTOR
VALUE
1
2
3
4
RESISTOR NOT REQ’D.
133 OHM
68.1 OHM
45.3 OHM
ALL RESISTORS
1/4 WATT
1% METAL FILM
1
POWER SUPPLY PROVIDES OVERLOAD PROTECTION AND
DISCONNECT MEANS.
2
ALLOW UP TO 0.5 AMPS FOR EACH DEVICE. ACTUATORS AND
CONTROLLER CAN SHARE SAME TRANSFORMER PROVIDING THE
VA RATING OF THE TRANSFORMER IS NOT EXCEEDED AND PROPER
PHASING IS OBSERVED. DO NOT MIX A.C. AND D.C. POWER SOURCES.
3
DO NOT MIX M984/6 OR MODUTROL MOTORS WITH THE ML7984 IN
THE SAME CIRCUITRY.
4
USE RESISTOR KIT PART NUMBER 272822.
M25498A
