Cooling Mode
The unit works as an air conditioner. Adjust fan speed and air temperature to suit your desired comfort
level. Temperature setting range is 16°C- 32°C (61°F- 89°F).
INSTALLATION (CONTINUED)
NOTE:
1.
2.
The supplied exhaust hose can be extended from 30 cm to 120 cm / 12 inches to 47 inches.
Do not bend (to the extent shown below) the exhaust hose. A bent hose will block exhaust air and
cause the unit to malfunction or shut-off.
RECOMMENDEDNOT RECOMMENDED
•
•
The length of the exhaust hose is determined by the product specifications. Do not replace or
lengthen it as this could cause the unit to malfunction.
Make sure the back of the unit is at least 50 cm / 20 inches away from the wall. Do not place the unit
in front of curtains or drapes as this could obstruct the airflow.
USE & OPERATION
TOUCH SCREEN CONTROL PANEL
POWER CONTROL
The Power Control turns the unit on and off.
MODE CONTROL
3 settings: Cool, Dehumidify, Fan.
A light will indicate which setting is currently being used.
(1) Timer Control
(4) Mode Control
(2) Fan Speed Control
(5) Power Control
(3) Timer / Temperature Set Controls
(6) Warning Light (when flashing)
50 cm / 20”
MIN. 36 cm / 14”
MAX. 102 cm / 40”
EN 4
MIN 35.6 cm
(1) (2) (3) (3) (4) (5) & (6)
