3EN
INSTALLATION
It is important that the installation instructions below are followed for successful installation of this
Portable Air Conditioner. Please call Customer Support if you have any difficulties or queries
regarding these installation procedures.
Installation Kit:
1. Window Bracket Kit (1 Set) 5. Exhaust Hose (1 Piece)
2. Window Bracket Panel Adapter (1 Piece) 6. Insulation Tape (gray,
adhesive)
(1 Piece)
3. Exhaust Hose Connector (1 Piece) 7. Insulation Tape (black,
adhesive)
(1 Piece)
4. Hole Cover (1 Piece) 8. Foam Insulation Pads
(non-adhesive)
(2 Pieces)
1 3
x1
x1x1
2
4
x1
5
x1
6
x1 x1
7 8
x2
To Next Page
