Chapter 6 — Printer Maintenance
54 MP Nova Mark II User Guide
Changeable Parts
Roller Replacement
s
1 Check that the printer is turned off and open the cover (see“Open and
Close the Printer Cover” on page 11).
2 Pull the roller and the roller bearing support to the right (use the rubber
surface when pulling right).
3 Lift the left-hand end of the roller toward the interior of the printer.
4 Lift out the right-hand end of the roller.
Note: The pictures shown describe an MP Nova4 DT. The process is the same
for all MP Nova Mark II printers.
