Honeywell NetAXS-123 User Manual

142 www.honeywell.com
Upgrade Notes
A.6 Upgrade Notes
1. If you notice any communication issues, and the upgrades are complete, you
probably had more than one panel configured as a gateway. In this case, you
should reset the panels to clear the issue.
2. If you are using Microsoft Internet Explorer 7—According to Microsoft, if you
are running IE7 version 7.0.5730.11, you should upgrade to version
7.0.5730.13 or newer. NetAXS™ is not compatible with IE7 version
7.0.5730.11. You should either use a newer version, IE 6, or another browser.
A.6.1 Microsoft Internet Explorer 7 Security Certificate Failure
Note: The IP address shown in the following screens is for illustration purposes only.
For these procedures use the default IP address that is provided to you.
If you are using Microsoft Internet Explorer 7, and you receive a certificate error
message, follow these steps to clear it:
1. Enter the IP address of the panel into the URL box. The following message
appears:
Figure A-9: Security Certificate Failure Screen

Honeywell NetAXS-123 Specifications

General

Readers supported	2
Operating voltage	12V DC
Humidity	5% to 95% non-condensing
Network Interface	10/100 Mbps Ethernet
Communication	TCP/IP
Power Supply	12 VDC
Outputs	2 relay outputs
Operating Temperature	0°C to 49°C (32°F to 120°F)
Users	Up to 10, 000
Event buffer	50, 000
Reader Interfaces	Wiegand, Clock/Data
Supported Readers	Wiegand
Supported Protocols	TCP/IP
Certifications	UL294, CE
Dimensions	165 mm H x 140 mm W x 45 mm D (6.5 in H x 5.5 in W x 1.8 in D)
