12 www.honeywell.com
Installing the PRO4200 Two Reader Module
Specification
Specification
The Two-Reader Module is for use in low voltage, class 2 circuits only.
Primary power:
12VDC + 10%, 650mA maximum with 5V readers, 300 mA max. excluding readers
Relay contacts
:
• Relays 0 through 1 outputs, Form-C, 5A @ 30VDC, resistive
• Relays 2,3,4, and 5 outputs, Form-C,2A @ 30VDC,resistive
Inputs:
• 8 supervised, End of Line resistors 1k ohm ± 1% tolerance
• 2 unsupervised dedicated inputs
Communication:
Wire requirements:
Mechanical:
Environment:
RS-485 Range 9,600 to 38,400 bps
Power 1 twisted pair, 18AWG
(Honeywell 3114 or equivalent
RS-485 24 AWG, 4,000 feet (1,200 m) max., twisted pair with
shield (120, 23pF) (Honeywell 3328 or equivalent)
Inputs 1 twisted pair per input, 30 ohms max.
Outputs As required for the load
Readers 6 conductors, 18AWG, 500 feet (150m) max. shield and
drain
Dimension 5.5" (140 mm) W x 9" (229 mm) L x 1" (25 mm) H
Weight 12 oz. (340 g) nominal
Temperature 0°C to +49°C, operating, -55°C to +85°C, storage
Humidity
0% to 85% RHNC
