Honeywell RM7838C1012 User Manual

RM7838B, RM7838C 7800 SERIES RELAY MODULES
32-00211—01 18
Fig. 25. RM7838B,C Relay Module exploded view.
HONEYWELL
POWER
PILOT
FLAME
MAIN
ALARM
RESET
KEYBOARD
DISPLAY
MODULE
PURGE
TIMER
WIRING
SUBBASE
CAPTIVE
MOUNTING
SCREW
RUN/TEST
SWITCH
CONFIGURATION
JUMPERS
RELAY
MODULE
SEQUENCE
STATUS
LED PANEL
RESET
BUTTON
FLAME
AMPLIFIER
EDIT:
BACK
- ENTER -
BURNER CONTROL
_
+
M22824
