Page #5 background imageLoading...
Page #5 background image
5
66-10853
RM7800E,G,L,M; RM7840E,G,L,M 7800 SERIES RELAY MODULES
บรษัท เอดีดี เฟอรเนส จํากัด
ADD FURNACE CO.,LTD.
44 ซอยบรมราชชนน 70 ถนนบรมราชชนน แขวงศาลาธรรมสพน์ เขตทวีวฒนา กรงเทพฯ 10170
โทร: 02-888-3472 โทร: ออกแบบ:08-08-170-170 แฟกซ์: 02-888-3258
https://www.add-furnace.com E-mail: sales@add-furnace.com
Table 2. Recommended Grounding Practices.
Ground Type
Recommended Practice
Earth ground (subbase and relay module).
1. Use to provide a connection between the subbase and
the control panel of the equipment. Earth ground must be
capable of conducting enough current to blow the 20A fuse
(or breaker) in the event of an internal short circuit.
2. Use wide straps or brackets to provide minimum length,
maximum surface area ground conductors. If a leadwire
must be used, use 14 AWG copper wire.
3. Make sure that mechanically tightened joints along the
ground path are free of nonconductive coatings and pro-
tected against corrosion on mating surfaces.
Signal ground (KDM, Data ControlBus Module™,
Communications Interface ControlBus™ Module).
Use the shield of the signal wire to ground the device to the
signal ground terminals [3(c)] of each device. Connect the
shield at both ends of the chain to earth ground.
Table 3. Terminal Ratings.
Terminal No.
Description
Ratings
G
Flame Sensor Ground
a
Earth G
Earth Ground
a
L2(N)
Line Voltage Common
3
Alarm
120 Vac, 1A pilot duty.
4
Line Voltage Supply (L1)
120 Vac (+10%/-15%), 50 or 60 Hz (±10%)
b,d
5
Burner Motor
120 Vac, 9.8 AFL, 58.8 ALR (inrush).
6
Burner Controller and Limits
120 Vac, 1 mA.
7
Lockout/Running Interlock
120 Vac, 8A run, 43A inrush.
8
Pilot Valve/Ignition
120 Vac
c
.
9
Main Fuel Valve
120 Vac
c
.
10
Ignition
120 Vac
c
.
F(11)
Flame Sensor
60 to 220 Vac, current limited.
12
Firing Rate High Fire
120 Vac, 75 VA pilot duty.
13
Firing Rate Common
120 Vac, 75 VA pilot duty.
14
Firing Rate Low Fire
120 Vac, 75 VA pilot duty.
15
Firing Rate Modulate
120 Vac, 75 VA pilot duty.
16
Unused
17
Unused
18
Low Fire Switch Input
120 Vac, 1 mA.
19
High Fire Switch Input
120 Vac, 1 mA.
20
Preignition Interlock Input
120 Vac, 1 mA.
21
Interrupted/Intermittent Pilot Valve/First Stage Oil Valve
120 Vac
c
.
22
Shutter
120 Vac, 0.5A.
.
a
The relay module must have an earth ground providing a connection between the subbase and the control panel or the
equipment. The earth ground wire must be capable of conducting the current to blow the 15A fuse (or breaker) in event of an
internal short circuit. The relay module requires a low impedance ground connection to the equipment frame, which, in turn,
requires a low impedance connection to earth ground.
b
2000 VA maximum connected load to relay module assembly.
c
See tables 4 and 5.
d
RM7800G,M/RM7840G,M operating frequency determined by relay module selection.
