Honeywell RTH2300 series User Manual

RTH2300/RTH221
5 69-2605ES—02
M32701
We
Lo
Batt
Wake
Set
am
Heat
75
On
6
:
30
Quick reference to display screen
Low battery warning
(see page 16)
Setpoint indicator
Appears when the
setpoint temperature
is displayed.
Temperature
The ambient (measured)
temperature is normally
displayed. To view the
setpoint temperature,
presstheUporDown
button once. The setpoint
temperature will appear
for five seconds.
System status
Cool on: Cooling system is on.
Heat on: Heating system is on.
WhenCoolOnisflashing,compressorprotectionisengaged(seepage15).
Current day/time
(see page 6)
Current program period
Wake/Leave/Return/Sleep
(see pages 9-10)
69-2605ES_A.indd 5 5/25/2011 11:51:47 AM

Honeywell RTH2300 series Specifications

General

Type	Programmable Thermostat
Display	LCD
Power Source	Battery
Temperature Range	40°F to 90°F (4°C to 32°C)
Stages	1 Heat/1 Cool
Backlight	No
Compatibility	Single Stage Heating and Cooling Systems
Voltage	24 VAC
Battery	2 AA batteries
