69-1716
Step 2. Follow Import
ant Instructions
1.
Do not connect the wires to the new thermostat
based on wire color because damage can occur to
the heating and/or cooling system.
These Installation Instructions explain late
r how to
use the enclosed wire labels to correctly mark the
wires connected to your old thermostat.
Step 3. Re
move Old Thermost
at
M22034
Y
G
RC
R
W
OLD THERMOST
A
T
RED
WHITE
YELLOW
ORANGE
GREEN
DO NOT WIRE
NEW THERMOST
A
T
BASED ON
WIRE COLOR.
!
4
6
