Honeywell RTH8500 Installation Guide

Installation Guide
8
About your new thermostatMark wallplate mounting position
1. Pull wires through
wallplate.
2. Level wallplate if desired. 3. Mark positions of
both screw holes.

Honeywell RTH8500 Specifications

General

Hold Feature	Yes
Compatibility	Works with most heating and cooling systems
Temperature Range	40°F to 90°F
Weight	250 g
Programmable	7-day programmable
Dimensions	4.5 x 3.5 x 0.9 inches (114 x 89 x 23 mm)
