Honeywell S7760A User Manual

74-3450—2 8
NOTES:
— Level 3 has the highest privilege while level 1 has
the lowest privilege.
— Initial settings for all passwords are 0
0 0 0.
Time
Use this screen to view or change the date and time. Press-
ing Apply saves the modified settings.
Main—>Settings—>Time
ROOFTOP UNITS (RTU)
Main—>BuildngVw—>RTU Data
The RapidZone Command Display provides access to equip-
ment data via the RTU Data screen. The list below contains
brief descriptions of the data available.
Duct Static Pressure: displays duct static pressure.
Control sensor: displays duct static pressure
Control Setting: displays static pressure setpoint (see
IMPORTANT below)
EPID Output: displays bypass damper position as a
percent open
Cooling Stages: displays the number of cooling stages that
are commanded on
Econ Mixed Air: displays mixed air temperature
Control sensor: displays mixed air temperature
Control Setting: displays mixed air setpoint (see
IMPORTANT below)
EPID Output: displays economizer damper position as a
percent open
Fan Command: displays the fan control output state
Heating Stages: displays the number of heating stages that
are commanded on
Mod Cooling: displays cooling valve position as a percent
open
Mod Heating: displays heating valve position as a percent
open
M18584
Time
Sept/7/2000
Month Day Year
9 : 40 : 12AM
Hour min sec
!!
+
-
Apply
Cancel
M18583
Rooftop Unit Data
Cooling Stages
Duct Static Press
Econ Mixed Air
Fan Command
Heating Stages
RTU Controller
!!
Schedule
-
Page Up
Page Down
1
2.3686 INW
57.3 DF
On
0
52.6 DF
