12 Sensing and Internet of Things
Sensor Evaluation Kit, SEK001
for Use with RSC, HSC, and SSC Series
Issue B
32324959
APPENDIX A. SEK001 SPECIFICATIONS
Table A1. SEK001 Specifications
Characteristic Parameter
Temperature range
1
20°C to 30°C [68°F to 86°F]
Humidity range
1
30 %RH to 70 %RH
Power supply:
internal (Arduino Uno Rev3)
external
3.3 V or 5 V
3.3 V or 5 V
Compatible sensors
RSC Series
HSC Series (digital verions only)
SSC Series (digital versions only)
Associated software
Sensor Evaluation Kit SEK001 Version 1.0.exe
Arduino Firmware SEK001 Version 1.0.zip
XLoader.zip
1
See Appendix B. Remote Connection if evaluation conditions are different.
Table B2. HSC Series, SSC Series Pinouts
Sensor
Pin
Function
SEK001
Socket
SPI I
2
C
DIP, SMT DIP, SMT SIP
1 GND GND GND 13
2 VCC VCC VCC NC
3 MISO SDA MISO 11
4 SCLK SCL SCLK 10
5 SS NC - GND
6 NC NC - 5V
7 NC NC - 9
8 NC NC - 12
Table B1. RSC Series Pinout
Sensor
Pin
SPI Function
(DIP, SMT)
SEK001 Socket
1 SCLK 13
2 DRDY NC
3 DIN 11
4 CS_ADC 10
5 GND GND
6 VCC 5V
7 CS_EE 9
8 VOUT 12
APPENDIX B. REMOTE CONNECTION
Use wire leads to connect a remotely-located sensor to either the sockets provided on the SEK001 or directly to the Arduino UNO
board. See Tables B1 and B2 for the correlating sensor pins and SEK001 sockets.
