6 Sensing and Internet of Things
Sensor Evaluation Kit, SEK001
for Use with RSC, HSC, and SSC Series
Issue B
32324959
Table 4. Sensor Selection Panel Screen Functions
Function Description
Sensor Type Select Pressure from the drop-down menu. (Note: Other selections are not currently available.)
Sensor Series Select RSC Series, HSC Series, or SSC Series from the drop-down menu.
(Note: Other selections are not currently available.)
Part Number
(Note: The last eight digits are
found on the sensor label.)
Slowly begin to enter the part number of the sensor to be evaluated until all but the last several
digits appear. Then, select the final part number from the remaining drop-down list. After the
part number appears, click on the SUBMIT button.
(Note: Do not enter the entire Part Number or copy/paste it into the field. The Part Number must
be selected from the drop-down list. )
Serial Number Not used.
RECENT SELECTIONS If applicable, a part number may be selected from this list directly. It is not necessary to enter
the Sensor Type or Series first.
4.0 SOFTWARE SCREENS
4.1 Sensor Selection Panel Screen (see Figure 5 and Table 4)
)
Figure 5. Sensor Selection Panel Screen
