Honeywell SEK001 User Manual

Sensing and Internet of Things 3
Sensor Evaluation Kit, SEK001
for Use with RSC, HSC, and SSC Series
Issue B
32324959
2.4 Connect the SEK001 to the Arduino Uno Rev3 to form the SEK001/Arduino Assembly
Place the SEK001 over the Arduino Uno Rev3 and align all pins and sockets. Gently, but firmly, press both boards together until
the SEK001 is seated on top of the Arduino Uno Board (see Figure 2).
Figure 2. SEK001/Arduino Assembly
3.0 DOWNLOAD AND INSTALL SOFTWARE AND FIRMWARE
3.1 Follow the steps given in Table 3.
Arduino Uno Rev3
SEK001
HSCDRNN001ND2A5
