Honeywell T5 Quick Install Guide

8
7 Record if you have wires in the following terminals
Do not include jumpers as a part of your count. The thermostat does not need
jumpers.
Terminal Wire Color
R
R h
Rc
8 Write down the color of the wires
Check mark the wires that are connected to terminals. Next to the check mark,
write down the color of the wire. Do not include jumpers as a part of your count.
Check all that apply (Not all will apply):
Terminal Wire Color
Y
Y2
G
Terminal Wire Color
A or L/A
O/B
W2 or AUX
C
Required
E
W
K
S and U terminals are not supported with this thermostat.
If there are wires in terminals that are not listed, you will need additional wir-
ing support. Visit yourhome.honeywell.com/support to find out if the thermo-
stat will work for you.

Honeywell T5 Specifications

General

Model	T5
Type	Programmable Thermostat
Connectivity	Wi-Fi
Display	Touchscreen
Temperature Range	40°F to 99°F (4°C to 37°C)
Humidity Control	No
Remote Access	Yes, via Honeywell Home App
Compatibility	Amazon Alexa, Google Assistant, Apple HomeKit
Scheduling	7-day programmable
Stages	1 Heat / 1 Cool
Features	Smart Alerts
Dimensions	4.06 in. high x 4.06 in. wide x 1.06 in. deep
