Honeywell T775P2003 Installation Instructions

T775P SERIES 2000 ELECTRONIC STAND-ALONE CONTROLLER
21 62-0256—11
Fig. 45. Setup - Outputs - Stage - Reset Runtime.
1.3.4.1.1. RESET RT (run time)
This selection displays only if “Show RT = YES” is
selected during Output Options setup (see Fig. 41).
1. Press the  button to display the Reset RT values.
2. Use the  and  buttons to select YES or NO.
Default: NO
3. Press the  button to accept the value and return to
the Stage menu.
Selecting YES immediately resets the relay output run
time hours to zero for this stage. When you subsequently
return to this screen, the RESET RT defaults to NO.
NOTE: Run times can be reset to zero for the first
four (4) stages. You must do this for each of
the stages (1-4) that you want to reset to zero.
Fig. 46. Setup - Outputs - Stage - Exit.
1.3.4.1.2. Exit Stage Setup
Press the  button (or highlight EXIT and press the 
button) to exit the current Stage setup and return to the
Outputs menu.
To setup the next stage go to “1.3.4. Setting up the
Stages” on page 20.
To setup the last stage, continue with “1.3.5. Setup Last
Output”.
Fig. 47. Setup Last Output.
1.3.5. Setup Last Output
The last relay output is available to be configured as the
pump output.
1. From the Outputs menu, use the  and  buttons
to highlight the last Stage (Fig. 47 shows Stage 4 as
the last relay output).
If used, the pump output will be either 4, 8, or 12
depending on the number of stages. See “1.3.1.
Number of STAGES” on page 15.
2. Press the  button to display the Stage/Pump
menu.
NOTE: Reset RT displays only if “Show RT = YES” is
selected during Output Options setup (see
Fig. 41).
Fig. 48. Setup Pump Output.
1.3.6. Enable/Disable Pump Output
1. From the Stage/Pump menu, use the  and  but-
tons to highlight the PUMP OUT option.
2. Press the  button to display the Pump Out menu.
3. Use the  and  buttons to select YES or NO.
Default: NO
4. Press the  button to accept the value and return to
the Stage/Pump menu.
NOTE: The pump output energizes whenever any
stage is energized.
If you do not have a pump output, select NO and press
the  button to exit this screen. Go to “1.3.7.5. Pump Exit”
on page 23.
Selecting YES displays the pump options on the Pump
menu when you exit this screen.
SETUP
OUTPUTS
STAGE 1
SHOW RT
RESET
RUN TIME
FOR
STAGE 1
M24672
YES
NO
SETUP
OUTPUTS
STAGE 1
RESET RT
SETUP
OUTPUTS
STAGE 1
RESET RT
EXIT
M24673
SETUP
OUTPUTS
# STAGES
OPTIONS
STAGE 1
STAGE 2
STAGE 3
STG4/PUMP
EXIT
SETUP
OUTPUTS
M24674
SETUP
OUTPUTS
STG4/PUMP
RESET RT
PUMP OUT
EXIT
SETUP
OUTPUTS
STG4/PUMP
M24675
SETUP
OUTPUTS
STG4/PUMP
PUMP OUT
YES
NO
SETUP
OUTPUTS
STG4/PUMP
USE
STG4/PUMP
AS PUMP
OUTPUT
RESET RT
PUMP OUT
EXIT
