Honeywell Temaline TK-S014 User Manual

6 TK_S014 – Installation Manual
Compositions with phased out devices
Note: These compositions are done including some phase out devices cannot anymore be purchased. This
list is left here just for maintenance reference.
Terminals
Code Composition Notes
TK_D014 RTU-C01 + RTU-A08 + RTU-S01 + third
party Wiegand reader
Horizontal mounting.
Weight=0.65Kg
Power=2.8W
Current=210mA (Excluding reader current)
RTU-C01 + RTU-A08 + RTU-S01 + 2 third
party Wiegand readers
Horizontal mounting.
Weight=0.65Kg
Power=2.8W
Current=210mA (Excluding readers
current)
The 2 readers are on the same door one in
entry and one in exit direction
Terminals with Keyboards
Code Composition Notes
TK_T014 RTU-C01 + RTU-T01 + RTU-A08 + 2 RTU-
S01 + 1 third party Wiegand reader
Horizontal mounting.
Weight=1.05Kg
Power=3.3W
Current=240mA
(Excluding reader current)
RTU-C01 + RTU-T01 + RTU-A08 + 2 RTU-
S01 + 2 third party Wiegand readers
Horizontal mounting.
Weight=1.05Kg
Power=3.3W
Current=240mA (Excluding reader current)
The 2 readers are on the same door one in
entry and one in exit direction
Interactive Terminals with Keyboards
Code Composition Notes
TK_T214 RTU-C02 + RTU-B01 + RTU-A08 + 2 RTU-
S01 + 1 third party Wiegand reader
Horizontal mounting.
Weight=1.4Kg
Power=6.6W
Current=480mA (Excluding reader current)
RTU-C02 + RTU-B01 + RTU-A08 + 2 RTU-
S01 + 2 third party Wiegand readers
Horizontal mounting.
Weight=1.4Kg
Power=6.6W
Current=480mA (Excluding reader current)
The 2 readers are on the same door one in
entry and one in exit direction

Honeywell Temaline TK-S014 Specifications

General

Brand	Honeywell
Model	Temaline TK-S014
Category	Control Unit
Language	English
