TH114-AF-GA / TH114-AF-GB
7
ENGLISH
NOTE: Connect the wires using the provided solderless connectors for copper wires.
Wiring diagrams
White
120 V
Load
Power
supply
Red
Black
Red
Red
Black
Black
Red
Black
240 V
Load
Power
supply
Red
Black
Red
Black
Black
Black
White
