The Thor VM1 can be connected to vehicle power as follows:
• Direct power connection (12-48VDC vehicles). See Connecting
the Power Cable, below.
• Replace a previously installed VX6/VX6 or Thor VX8/VX9 with an
adapter cable. See Adapter Cables, below.
• High voltage forklifts (over 60V). Refer to the “DC/DC Power
Supply Installation Instructions,” available at
www.honeywellaidc.com.
Connecting the Power Cable
The following power option is for 12-48VDC vehicles (10-60VDC
direct connection).
• Refer to the wiring diagram for wire colors and connections.
CAUTION - For installation by trained service personnel only.
Fuse Requirements
WARNING - For proper and safe installation, the input power
cable must be connected to a fused circuit on the vehicle. If
the supply connection is made directly to the battery, the fuse
should be installed in the positive lead within 5 inches of the
battery’s positive (+) terminal. The fused circuit requires a
maximum time delay (slow blow) fuse with a current rating as
noted below.
• F o r 12VDC input, use a 10A slow blow fuse that has a DC
voltage rating greater than 12VDC.
• F o r 24VDC input, use a 6A slow blow fuse that has a DC
voltage rating greater than 24VDC.
• F o r 36VDC input, use a 4A slow blow fuse that has a DC
voltage rating greater than 36VDC.
• F o r 48VDC input, use a 3A slow blow fuse that has a DC
voltage rating greater than 48VDC.
Note: For North America, a UL Listed fuse must be used.
